SPECIFICATION
Assists in the compliance of regulations BS 5266 and BS EN 1838:2013 for emergency lighting in commercial, public and accommodation premises. Maintained operation ensures that the sign is always illuminated whilst the mains power supply is active. When the mains power supply is lost, the unit will operate for a minimum of 3 hours, ensuring that occupiers have clear, illuminated exit route guidance during evacuation.
Downloadable Product Files
| Adjustable | Height Adjustable |
| Average Life | 25,000 hrs |
| Body Colour | White |
| Body Material | Polycarbonate |
| Box Contents | Fitting, Fixings, 4 Legends (Up, Down, Left & Right) and Instructions |
| Brand | LightHub |
| Cable Entry | Top of Unit |
| Cap Type | Integrated LED |
| Colour Rendering Index (CRI) | >=80 |
| Colour Temperature Description | Daylight White |
| Colour Temperature Value | 6000K |
| Conduit Knockouts | None |
| Dimmable | Non-Dimmable |
| Domestic/Commercial Use | Commercial |
| Earth Protection | Class II (No Earth) |
| Emergency (Yes/No) | Yes |
| Emergency Battery Life | >3 Hours |
| Emergency Battery Type | LiFePO4 (Replaceable) |
| Emergency Lighting Maintained | Maintained or Non-Maintained |
| Emergency Viewing Distance | 25 Metres |
| Emergency Voltage | 3.2V 1500mAh |
| Emergency Wattage | 3.0W |
| Fitting Installation | Ceiling |
| Fixings Supplied | Yes |
| Indoor/Outdoor Usage | Indoor |
| Installation Options | Ceilings, Corridors, Doorways, Emergency Escape Routes, Stairwells etc |
| IP Rating | IP20 |
| kWh Per 1000hr Life | 4 |
| Diffuser Colour | Clear with frosted centre |
| Diffuser Material | Acrylic |
| Light Technology | LED SMD 2835 |
| Luminous Flux | 90 lm |
| Luminous Flux (Emergency Mode) | 48 lm |
| Lumens per watt | 30 lm/w |
| Manufacturer Guarantee | 3 years (fitting), 2 years (battery) |
| Model Range | EDGE |
| Model No | EXHGWS |
| Operating Temp (°C) | -5 to 40 °C |
| Pack Size | 1 Unit |
| Power Input | Mains (Hardwired) |
| Power Factor Value | 0.9 |
| Product Dimenions (H x W x D) | Height: 480-700mm x Width: 300mm x Depth: 45mm |
| Product Type | Emergency Exit Light |
| Product Weight | 1.10 kg |
| Shape | Rectangle |
| Smart Compatibility | No |
| Transformer | Internal Driver |
| UKCA & CE Compliant | Yes (Conformity Certificate Available) |
| UK & EU Regulations | BS EN 60598-2-22 |
| Voltage | 220-240 |
| Voltage Supply | AC 50/60Hz |
| Wattage | 3.0W |
