SKU : EXHGWS

This illuminated LED fire exit sign comes complete with 4 green running man legends; Up, Down, Left and Right directional arrows. The LED box style is typically installed above a doorway but can also be installed on other wall locations.

  • 6000K, Daylight White
  • Legends can be installed either side of unit
  • 25M Viewing distance
  • 3hr Emergency maintained and non-maintained
  • Up, Down, Left and Right legends included

Read More

EDGE Emergency Exit Running Man Sign | LED 3W 200LM | 6000K Daylight | IP20 | Surface Mounted Suspended

50+ In stock Pre-order Now Order now, Only 27 left! Sold Out

Regular price £34.95 £29.95


/
inc VAT

SAFE & SECURE SHOPPING

American Express Apple Pay Google Pay KlarnaMastercardPayPalShop Pay Visa
EDGE Emergency Exit Running Man Sign | LED 3W 200LM | 6000K Daylight | IP20 | Surface Mounted Suspended

SPECIFICATION

Assists in the compliance of regulations BS 5266 and BS EN 1838:2013 for emergency lighting in commercial, public and accommodation premises. Maintained operation ensures that the sign is always illuminated whilst the mains power supply is active. When the mains power supply is lost, the unit will operate for a minimum of 3 hours, ensuring that occupiers have clear, illuminated exit route guidance during evacuation.

    Average Life 25,000 hrs
    Body Colour White
    Body Material Polycarbonate
    Box Contents Exit Fitting, Up Down Left Right Legends, Instructions & Fixings
    Brand LightHub
    Cable Entry Rear of ceiling bracket
    Cap Type Integrated LED
    Colour Rendering Index (CRI) >=80
    Colour Temperature Description Daylight White
    Colour Temperature Value 6000K
    Conduit Knockouts None
    Dimmable Non-Dimmable
    Domestic/Commercial Use Commercial
    Earth Protection Class II
    Emergency (Yes/No) Yes
    Emergency Battery Life >3 Hours
    Emergency Battery Type LiFePO4 (Replaceable)
    Emergency Lighting Maintained Maintained or Non-Maintained
    Emergency Viewing Distance 25 Metres
    Emergency Voltage 3.2V 1500mAh
    Emergency Wattage 3.0W
    Fitting Installation Ceiling
    Fixings Supplied Yes
    Indoor/Outdoor Usage Indoor
    Installation Options Ceilings, Corridors, Doorways, Emergency Escape Routes, Stairwells etc
    IP Rating IP20
    kWh Per 1000hr Life 3
    Diffuser Colour Clear
    Diffuser Material Polycarbonate
    Light Technology LED SMD 2835
    Luminous Flux 90 lm
    Luminous Flux (Emergency Mode) 48 lm
    Lumens per watt 30 lm/w
    Manufacturer Guarantee 3 years (fitting), 2 years (battery)
    Model Range EDGE
    Model No EXHGWS
    Operating Temp (°C) -5 to 40 °C
    Pack Size 1 Unit
    Power Input Mains (Hardwired)
    Power Factor Value 0.9
    Product Dimenions (H x W x D) Height: 480-700mm x Width: 300mm x Depth: 45mm
    Product Type Exit Light
    Product Weight 1.10 kg
    Shape Rectangle
    Smart Compatibility No
    Transformer Internal Driver
    UKCA & CE Compliant Yes (Conformity Certificate Available)
    UK & EU Regulations BS EN 60598-2-22
    Voltage 220-240
    Voltage Supply AC 50/60Hz
    Wattage 3.0W
